the perfect mix of art and technology
AT 8.1 OW
The Cine Series AT 8.1 OW has been designed around the unique Ariatechnik Wave Synergy™ drive unit to bring audiophile performance to a wide range of installation applications. A modular, two-way point source loudspeaker that is intended for use in media rooms, home theaters or anywhere a high output loudspeaker with a wide coverage pattern is required. These loudspeakers deliver class leading accuracy, sensitivity and dynamics. Characteristic of the Wave Synergy™ design is a very wide 'sweet spot' with an exceptionally even response throughout the listening area, as well as an extraordinary transient response.
The AT 8.1 OW primary role is as an on wall loudspeaker. It can also be used in cabinets, behind screen, or as an in room loudspeaker.
Utilizing our amplification's digital signal processing, the system can correct for each of these unique placement applications with relative ease. The AT 8.1 OW may also be deployed in either passive or active mode to accommodate individual system requirements by utilizing fewer channels of amplification where appropriate. The other advantage to the AT 8.1 OW is that it can be used either vertically or horizontally with no impact on performance or dispersion unlike all other non point source based loudspeakers.
TECHNICAL SPECIFICATIONS
SYSTEM
Frequency Response
(Active Mode)
Nominal Dispersion
Directivity Factor (Q)
Directivity Index (DI)
Dynamic Range
Maximum SPL
Crossover Type
Transducers
Native Sensitivity (1W/1M)
Mid -Woofer
Tweeter
Power Handling
Average (A.E.S)
Program
Peak
Nominal Impedance
95 Hz - 30 kHz ±3 dB
77 Hz - 40 kHz - 10dB
90˚ conical
5.8
7.0
106 dB
121 dB peak
Active is standard
Passive optional
200 mm (1 x 8”) constant
directivity Wave Synergy™
transducer
93 dB
109 dB
200 Watts
350 Watts
600 Watts
8 Ohms
CONSTRUCTION
Enclosure
Finish
Connectors
Dimensions (HxWxD)
Weight
Shipping Weight
ACCESSORIES / OPTIONS
Magnetic grill
Passive Crossover
MDF, sealed and internally braced
Black Anthricite Nextel™ (standard)
Custom finishes available
Neutrik Speakon NL4MP-ST
14.25” x 19” x 5.5” / 361.95 x 482.6 x 139.7 mm
15.9 kg (35 lbs)
19.1 kg (42 lbs)
Black fabric
1.8 k.Hz
electro-acoustic
Specifications subject to change without notice, please verify
specifications in advance when dealing with critical applications.
Ariatechnik operates under a continuous research and development routine.
Full specification PDF
