The AT 4.1 Full Range (FR) is a highly unique offering.  It shares the cabinet size and shape with the AT 5.1 WS but uses a full range
4” mid-woofer that allows a super compact speaker to deliver deep bass in a tiny package. The AT 4.1 FR is designed to be used in home music or media systems where a subwoofer is not possible but full range sound is desired. They are ideal for use in cabinets or on shelving units, mantles or bookshelves. The AT 4.1 FR delivers very big sound in a diminutive package with a truly musical presentation while taking up much less of your living and
visual space.

















Wave Synergy™

Characteristic of the Ariatechnik Wave Synergy™ loudspeaker design is that it presents a large 'sweet spot' both vertically and horizontally with an exceptionally even response throughout the listening area, as well as an extraordinary transient response. The Wave Synergy™ driver is effectively two drivers properly merged into one where, unlike ordinary drive units, the high frequency unit is positioned on the back of the low frequency driver and in the proper phase alignment with the high frequency driver. As a result they are on the the same time axis, so ensuring that sound energy effectively propagates from the same point and is delivered through the center of the low frequency cone as true point source.



Such integration optimizes reproduction quality by providing a constant time delay over the frequency spectrum, exceptional transient performance, wide dispersion and superior harmonic alignment, all of which delivers to the listening position a natural, clean and integrated sound with greatly enhanced intelligibility, sound staging and dynamics.



SYSTEM

Transducer:



Driver Description:





















Crossover Type:

Power Handling:



Native Sensitivity:

Frequency Range:



Nominal Impedance:



Ariatechnik 4" Concentric Driver with

1" Silk Tweeter 4 Ohm system impedance

The Ariatechnik 4” Point Source driver is a

full-range concentric loudspeaker providing high

quality sound in a very compact format featuring

a 4" aluminum coned woofer mated with a 1"

soft dome tweeter. The Aluminum woofer

provides a good balance between stiffness,

low mass and damping making for a very

natural sounding driver with a smooth frequency

response. The soft dome tweeter provides detailed and clear high frequencies with
minimal distortion

Passive network

Program: 80 Watts

peak: 250 Watts

86 dB woofer 88.5 dB tweeter

64 Hz - 25 kHz +/- 3 dB

59 Hz - 3 kHz -10 dB

4 Ohms

CONSTRUCTION

Material:



Dimensions of speaker without grill: (HxWxD)

Dimensions of Grill:

(HxWxD)



Weight:



1MDF with various wood veneers



11" x 6.5” x 5.5”

279.4mm x 165.37mm x 139.7mm

10.5“ x 6” x .250”

266mm x 152.4mm x 6.35mm



9.2 lbs

4.17 kg



Specifications subject to change without notice, please verify

specifications in advance when dealing with critical applications.

Ariatechnik operates under a continuous research and development routine.
